Relly#1 .3

Relly#1 .3

Weight:
1650 kg
Width:
1250 mm
Drive hydraulics:
40 l/min
Battery pack:
Lithium-ion
Battery Capacity:
315 Ah / 430Ah
Battery Voltage:
100 V
Battery Power:
30 kWh / 44 kWh
Working time:
5 / 8 hours
Charging time 220 V:
8 / 12 hours
Power:
25 kW
Speed:
18 km/u
Lifting capacity:
1250 kg
Download brochure electric
Weight:
1350 kg
Width:
1250 mm
Drive hydraulics:
40 l/min
Wheel drive:
Orbitmotor
Number of cilinders:
4
Power:
25 pk / 44 pk
Speed:
18 km/u
Engine:
Kubota V1505 / Kubota V1505 CRT
Lifting capacity:
1000 kg
Download brochure diesel

About the Relly#1 .3

  • Adjustable steering wheel with integrated Smart Modus
  • All auxiliary hydraulic functions can be set using Smart Modus
  • All machines come with an electrical shock arrestor for the extra function
  • Minimal number of hydraulic hoses passing through the articulation because of a proportional valve block
  • Precise, light and easy-to-operate boom

The advantages

  • Low pivot point
  • Attachments are always highly visible from the seat
  • Compact and light-weight machine
  • Top speed of 18 km/h
  • User-friendly
  • Plenty of room to mount and dismount
  • Attachments are interchangeable, thanks to the well-known quick coupling system
  • All machines come with two double-acting extra auxiliary hydraulic functions
  • All machines come with hose guards and sleeves on the cylinders

Try the Relly dashboard

Attachments

Layer clamp
Mixer bucket

The RELLY mini-loader in action!

Request quote

Interested?
build your own RELLY!
